Flat Rubber Hose
Product Overview
Our flat rubber hose is a premium-grade, collapsible hose engineered for high-performance fluid transfer in demanding industrial environments. Designed to lie completely flat when not in use, this innovative flat rubber hose maximizes storage efficiency and ease of handling, making it an ideal choice for applications requiring compact, portable solutions. Constructed from high-quality synthetic rubber compounds, it offers exceptional durability, flexibility, and resistance to abrasion, chemicals, and environmental stressors.
Available in a range of sizes and configurations, the flat rubber hose supports pressures up to 10 bar and temperatures from -20°C to +80°C, ensuring reliable operation across diverse conditions. Whether for water delivery, slurry transport, or temporary piping in construction sites, this hose delivers superior flow rates while minimizing drag and kink issues common in traditional round hoses. As a trusted solution in international trade, our flat rubber hose meets stringent global standards, including ISO 9001 certification, providing B2B buyers with confidence in quality and consistency.
Key Features
- Collapsible Design: Rolls flat to 90% of its expanded diameter, facilitating effortless storage, transportation, and deployment in tight spaces.
- Reinforced Construction: Multi-ply synthetic textile reinforcement embedded within rubber layers ensures high burst pressure and structural integrity under repeated use.
- Chemical and Abrasion Resistance: Formulated with EPDM or SBR rubber for superior resistance to oils, acids, UV exposure, and mechanical wear.
- Lightweight and Flexible: Weighs up to 50% less than comparable steel-wire reinforced hoses, enhancing maneuverability without compromising strength.
- Customizable Fittings: Compatible with standard camlock, Storz, or NPT couplings for seamless integration into existing systems.
- Non-Toxic Lining: Food-grade options available for potable water applications, compliant with FDA and EU regulations.
These features position the flat rubber hose as a versatile, cost-effective alternative to rigid piping, reducing operational downtime and maintenance costs for industrial users worldwide.
Technical Specifications
| Model | ID (mm) | OD (mm) | Working Pressure (bar) | Burst Pressure (bar) | Length per Roll (m) | Weight (kg/m) | Temperature Range (°C) |
|---|---|---|---|---|---|---|---|
| FRH-025 | 25 | 28 | 10 | 30 | 20-50 | 0.25 | -20 to +80 |
| FRH-038 | 38 | 42 | 10 | 30 | 20-50 | 0.38 | -20 to +80 |
| FRH-050 | 50 | 55 | 8 | 24 | 20-40 | 0.50 | -20 to +80 |
| FRH-063 | 63 | 69 | 8 | 24 | 15-30 | 0.65 | -20 to +80 |
| FRH-076 | 76 | 83 | 6 | 18 | 15-25 | 0.80 | -20 to +80 |
| FRH-102 | 102 | 110 | 5 | 15 | 10-20 | 1.05 | -20 to +80 |
| FRH-152 | 152 | 162 | 4 | 12 | 10-15 | 1.55 | -20 to +70 |
Note: Specifications are subject to customization. All flat rubber hoses undergo rigorous hydrostatic testing at 1.5 times working pressure.
Application Scenarios
The flat rubber hose excels in a variety of industrial and agricultural settings where mobility and space efficiency are paramount. In agriculture, it serves as a primary conduit for irrigation systems, enabling farmers to deploy high-volume water transfer across fields with minimal setup time. Its flat profile prevents tripping hazards and allows easy coiling on tractors or reels.
In construction and mining operations, the flat rubber hose handles slurry, drainage, and dewatering tasks, withstanding abrasive materials and rough terrains. Fire departments and emergency response teams rely on it for rapid deployment in firefighting lay-flat lines, where quick rollout and high flow are critical.
Additional scenarios include municipal water supply during roadworks, oilfield temporary piping for coolant transfer, and marine applications for bilge pumping. Its adaptability makes the flat rubber hose indispensable for global projects requiring reliable, temporary fluid management solutions.
Advantages
Opting for our flat rubber hose provides distinct advantages over conventional hoses. Firstly, its ultra-compact storage reduces logistics costs by up to 70% compared to bulkier alternatives, ideal for international shipping and on-site warehousing. The hose's inherent flexibility eliminates kinking, ensuring uninterrupted flow and extending service life beyond 5 years under normal conditions.
Superior material composition delivers ozone and weather resistance, preventing premature degradation in outdoor exposures. Economically, it lowers total ownership costs through reduced weight—facilitating manual handling without heavy machinery—and minimal maintenance needs. Environmental benefits include recyclability of rubber components and lower water waste from efficient flow dynamics.
In performance terms, the flat rubber hose achieves higher velocities at lower pressures, optimizing pump efficiency. Rigorous testing confirms compliance with EN ISO 1403 and RMA standards, guaranteeing safety and reliability for B2B applications worldwide.
Why Choose Us
As a leading manufacturer in the international trade of industrial hoses, we specialize in premium flat rubber hoses backed by decades of expertise. Our state-of-the-art production facilities employ advanced extrusion and vulcanization processes, ensuring batch-to-batch consistency and defect rates below 0.1%.
We hold certifications such as ISO 9001, ISO 14001, and CE marking, with full traceability from raw materials to finished products. Custom solutions are our forte—tailoring wall thickness, colors, or lengths to precise project specs. Our global supply chain supports bulk orders with lead times under 4 weeks, serving clients in Europe, Asia, and the Americas.
Commitment to innovation drives us: recent enhancements include anti-static linings for petrochemical use and antimicrobial coatings for hygiene-sensitive sectors. Partner with us for flat rubber hoses that deliver unmatched value, performance, and peace of mind.
FAQ
What is the maximum length available for a single flat rubber hose?
Standard rolls range from 10 to 50 meters, with custom lengths up to 100 meters possible via factory splicing for integrity.
Can the flat rubber hose handle hot water or steam?
Standard models support up to +80°C for water; high-temp variants reach +120°C. Steam applications require specialized models—consult specs.
Is the flat rubber hose suitable for potable water?
Yes, NR/EPDM food-grade versions comply with FDA 21 CFR 177.2600 and EU 1935/2004, ensuring safe drinking water conveyance.
How does the flat rubber hose compare to PVC lay-flat hoses?
Rubber offers superior abrasion resistance, flexibility in cold weather, and longevity (3x PVC lifespan), though PVC is lighter for low-pressure uses.
What maintenance is required for flat rubber hose?
Store coiled in shaded, dry areas; rinse after use; inspect for cuts annually. Avoid prolonged sun exposure or sharp bends.
Are fittings included with the flat rubber hose?
Fittings are optional. We crimp or vulcanize aluminum, brass, or stainless steel ends to order for leak-proof connections.
